Naval brass
NP1
C46200
- High Heat Resistance & High Conductivity
- Corrosion Resistance
Cu-Zn brass with a small amount of Sn added to improve corrosion resistance.
Compared with common brass (C26000, C26800, C28000), it can be used even in seawater or high-humidity environments.
Being a brass, it offers high tensile strength and wear resistance with excellent workability.
Positioning map
Main features
- Excellent corrosion resistance(seawater and high-humidity environments).
- Excellent strength and wear resistance.
- Good workability.
Chemical composition
The chemical composition of NP1 is as follows.
（Weight %）
| Cu | Sn | Zn |
|---|---|---|
| 61.0-64.0 | 0.7-1.0 | Rem. |
Technical Data
Mechanical properties
The mechanical properties of NP1 are as follows.
| Typical value | |||
|---|---|---|---|
| Thickness (mm) |
0.8-20 | 20-40 | 40-125 |
| Tensile Strength (N/mm²) |
400 | 400 | 375 |
| Elongation (%) |
50 | 50 | 50 |
| Vickers Hardness* (HV) |
100 | 100 | - |
